GOOGOL Generator

GOOGOL advantages:

With the same power and the same performance, the price is better. Our company has reached a strategic cooperation with Pangu and can quote under the name of our own brand, control prices and labels, and operate well.

Generator

The generator is a key component that converts kinetic energy into electrical energy, and the two most important factors affecting the performance of the generator are the materials used in the generator and the excitation method of the generator.

Next Product Inquire Now Request For Quote

Details

Materials

Materials:

The silicon steel sheets used by our company are all silicon steel sheets from Shanghai Baowu Steel (formerly Shanghai Baosteel). And the copper wire of Guancheng Datong (a listed company) is used; good raw materials are the basis for ensuring performance.

The internal copper wire winding of the HP motor is 20% higher than the national standard to achieve lower thermal attenuation performance, higher conversion efficiency of kinetic energy and electrical energy, and under the same power output, our generator feedbacks less resistance torque to the engine end, and the diesel engine is more labor-saving, that is, using our generator under the same engine; the overall anti-sudden load ability of the unit is stronger, and the current, voltage and frequency are more stable.

Excitation method:

All HP generators, regardless of size, are equipped with a brushless self-excitation system as standard, with low heat generation, no electric sparks, and can be maintenance-free for life.

Brushless motor: The only friction part in the motor is dust. Safer (lifetime maintenance-free)

Get a Quote

Product Details

Type	Set power			Diesel engine model	Cylinder number(mm)	Bore*stroke	Swept volume(L)	Fuel consumption rate(L/h)	Set coolant	Engine oil ststem capacity	DimensionLWH(mmmmmm)	Weight(kg)
Type	Master		Standby	Diesel engine model	Cylinder number(mm)	Bore*stroke	Swept volume(L)	Fuel consumption rate(L/h)	Set coolant	Engine oil ststem capacity	DimensionLWH(mmmmmm)	Weight(kg)
HP-K310	280	310		PTA780G3	6	128*166	12.8	78.49	18	40	300011101555	2563
HP-K330	300	330		PTA780G5	6	128*166	12.8	83.56	18	40	310011101555	2630
HP-K36	320	360		PTAA780G1	6	128*166	12.8	88.04	18	40	310011101555	2645
HP-K400	360	400		PTAA780G3	6	128*166	12.8	98.14	18	40	315011101555	2750
HP-K440	400	440		PTAA890G1	8	128*142	14.6	112.86	20	28	290014002080	3000
HP-K500	450	500		PTAA1120G1	10	128*142	18.3	129.61	21	34	320014002080	3400
HP-K550	500	550		PTAA1120G3	10	128*142	18.3	143.85	21	34	320014002080	3575
HP-K620	560	620		PTAA1340G3	12	128*14	21.9	52.14	23	36	370014002080	4110
HP-K660	600	660		PTAA1340G5	12	128*142	21.9	162.39	23	36	370014002080	4200
HP-K704	640	704		PTAA1780G3	16	128*142	29.2	169.79	32	48	440021402320	5590
HP-K800	720	800		PTAA1780G5	16	128*142	29.2	190.25	32	48	450021402320	5850
HP-K880	800	880		PTAA1780G7	16	128*142	29.2	207.77	32	48	460021402320	6201
HP-K880	800	880		QTA2160G1	8	170*195	35.4	204.87	70	160	490019202350	7606
HP-K1000	900	1000		QTA2160G5	8	170*195	35.4	22337	70	160	490019202350	8257
HP-K1100	1000	1100		QTA2160G7	8	170*195	35.4	252.38	70	160	490019202580	8682
HP-K1100	1000	1100		QTA3240G1	12	170*195	53.1	251.58	100	180	540022102800	10092
HP-K1320	1200	1320		QTA3240G5	12	170*195	53.1	301.73	100	180	540022102800	10559
HP-K1500	1350	1500		QTA3240G7	12	170*195	53.1	339.16	100	180	540022102800	10951
HP-K1650	1500	1650		QTA3240G9	12	170*195	53.1	376.97	100	180	560022102930	12180
HP-K1800	1600	1800		QTA4320G3	16	170*195	70.8	403.59	140	240	610026202980	13303
HP-K2000	1800	2000		QTA4320G5	16	170*195	70.8	453.17	140	240	630026202980	14227
HP-K2200	2000	2200		QTA4320G7	16	170*19	70.8	503.02	40	240	700026203390	17402
HP-K2200	2000	2200		QTA5400G1	20	170*195	88.5	508.97	200	300	810034703850	20593
HP-K2420	2200	2420		QTA5400G3	20	170*195	38.5	554.85	200	300	830034703850	21318
HP-K2640	2400	2640		QTA5400G5	20	170*195	88.5	605.16	200	300	830034703850	22128

Accessories

Controller

HG Smart（HGM) / UK DSE

All electronic components used in our control cabinets are ABB or Schneider brands, ensuring the stability of the unit's switching power supply and control circuit, and preventing the machine from false alarms or shutdowns due to circuit breaker relay failures.

Water Tank

Our company uses copper water tanks, not aluminum water tanks. Copper water tanks (cost 50% higher than aluminum water tanks) are corrosion-resistant, have good thermal conductivity, and good ductility; they have a long service life and are maintenance-free for life; they can ensure that the diesel engine does not overheat under extreme conditions, and that full-load operation is more stable. The life of a copper water tank is twice that of an aluminum water tank. Once used frequently, the copper water tank can extend the efficiency of the machine a little bit further under use.

Chassis

The base is an important structural component of a generator set, and the strength of the body depends entirely on the chassis of the unit.

Our company's standard units without boxes are all channel steel or I-beams. The channel steel used by our company is a one-piece hot-formed material with high structural strength and thickened bends; it has better stability, is more solid, and has better load-bearing capacity, ensuring that the unit still maintains the factory installation accuracy after frequent handling.

The shock-absorbing pads installed on the chassis are all high-quality stainless steel bowl-shaped shock-absorbing pads. The force-bearing area is larger. The center of the installation hole is not easy to offset, the service life is longer, and the load-bearing range is configured according to the dynamic load of the unit, which is 3 times the weight of the engine, ensuring that the installation hole of the unit is accurate and stable throughout the life cycle without offset.
